SP 6.5CM — MIDRANGE BEST SELLER 6.5"/16.5 CM
SP 6.5CM is a 6.5"/16.5 cm midrange loudspeaker from the SP Audio BEST SELLER line: 120 W RMS, 240 W peak, 4 ohm, 96 dB sensitivity, 30.5 mm (1.2") EISV voice coil, 25 Oz ferrite magnet and aluminium solid phase plug. Sold as a pair.
Technical specifications
| Nominal diameter | 165 mm (6.5") |
| Rated impedance | 4 ohm |
| Minimum impedance | 3.2 ohm |
| Rated power (RMS) | 120 W |
| Peak power (MAX) | 240 W |
| Sensitivity | 96 dB SPL 1W/1M |
| Frequency range | 100 Hz - 20 kHz |
| Voice coil diameter | 30.5 mm / 1.2" EISV |
| Winding material | 220 °C aluminum wire |
| Magnet | 25 Oz ferrite |
| Phase plug | Aluminium, solid |
| Suspension | M-ROLL, polycotton |
| Cone | Compressed paper, fiberglass, black painting |
| Sold as | Pair (2 pieces) |
Thiele-Small parameters
| Fs | 118 Hz |
| Re | 3.2 ohm |
| Qts | 0.624 |
| Qes | 0.671 |
| Qms | 9.061 |
| Vas | 4.67 L |
| Xmax | 2.0 mm |
| Sd | 147 cm² |
| Cms | 151.28 µm/N |
| Mms | 12.06 g |
| Bl | 6.53 TM |
| η0 | 1.101 % |
Frequently asked questions
How much power does the SP 6.5CM handle?
120 W RMS continuous and 240 W peak, per speaker.
What impedance is it and which amplifier does it need?
4 ohm nominal, 3.2 ohm minimum. Use an amplifier able to deliver about 120 W RMS at 4 ohm on each channel.
Is the price for one unit or for a pair?
The price is for a pair, two speakers.
What size is it and how big is the voice coil?
Nominal diameter 165 mm (6.5"), voice coil 30.5 mm (1.2").
What is the magnet and the phase plug made of?
A 25 Oz ferrite magnet and a solid aluminium phase plug, which helps dissipate heat from the voice coil.
